ISOMETER® isoGEN413R

Insulation monitoring device for mobile generators
Protective isolation with insulation monitoring and shutdown
In Accordance with DIN VDE 0100-551 and DIN EN 61557-8
Two Response values (Factory settings 46 kΩ, 23 kΩ)

The ISOMETER® isoGEN413R monitors the insulation resistance of un-earthed AC, AC/DC and DC systems (IT systems) with nominal mains voltages of 3(N) AC, AC/DC 0…400 V or DC 0…400 V. The maximum permissible mains leakage capacitance C_e is 5 μF. The DC-powered components present in AC systems have no effect on the response behaviour provided that a load current of at least DC 10 mA is flowing. The potentiometer scale is specifically adapted to typical setting values. Thanks to its integrated power supply (DC 12…48 V), the isoGEN413R-1 can also be powered by vehicle batteries, making it suitable for the continuous offline monitoring of a generator.

Questions? Contact us!

Insulation monitoring device for mobile generators
Protective isolation with insulation monitoring and shutdown
In Accordance with DIN VDE 0100-551 and DIN EN 61557-8
Two Response values (Factory settings 46 kΩ, 23 kΩ)

The ISOMETER® isoGEN413R monitors the insulation resistance of un-earthed AC, AC/DC and DC systems (IT systems) with nominal mains voltages of 3(N) AC, AC/DC 0…400 V or DC 0…400 V. The maximum permissible mains leakage capacitance C_e is 5 μF. The DC-powered components present in AC systems have no effect on the response behaviour provided that a load current of at least DC 10 mA is flowing. The potentiometer scale is specifically adapted to typical setting values. Thanks to its integrated power supply (DC 12…48 V), the isoGEN413R-1 can also be powered by vehicle batteries, making it suitable for the continuous offline monitoring of a generator.

Questions? Contact us!

Features

Monitoring of insulation resistance for unearthed AC/DC systems
Automatic adaptation to mains leakage capacitance up to 5 μF
Start-up, response and reset delays adjustable
Two separately adjustable response value ranges from 5…200 kΩ (AL1, AL2)
Alarms are output via LEDs (AL1, AL2), 1 alarm relay and Modbus RTU

Automatic device self-test with connection monitoring
Selectable relay behaviour: quiescent or operating current
Fault logging can be enabled
Modbus RTU & NFC

Applications

Mobile generators

Applied standards

IEC 60364-5-51
Electrical installations of buildings – Part 5-51: Selection and erection of electrical equipment – Common rules
BGI 608
BG Bau: Selection and operation of electrical installations and equipment on construction and assembly sites
DIN VDE 0100-551
Installation of low-voltage systems – Part 5-55: Selection and installation of electrical equipment – Other equipment – Section 551: Low-voltage power generation equipment
