LINETRAXX® PEM735-measuring case

LINETRAXX® PEM735-measuring case

  • Two "clicks" to the power quality report according to EN 50160
  • Class A measuring device in accordance with IEC 61000-4-30
  • Record of 15-min-mean values over 1.5 years
  • Easy-to-operate web interface
  • High accuracy of 0.2 S and high sampling frequency of 25.6 kHz

The PEM735 measuring and demonstration case is a complete mobile measuring set for power quality analysis according to DIN EN 50160 (measurement acc. to IEC 61000-4-30 class A).

Content of the measuring case

  • Universal measuring device PEM735
  • Integrated WLAN router
  • 4 flexible Rogowski coils and transducers for current measurement 100…4000 A
  • 1 current transformer clamp C112 (1000 A; 5 kHz)
  • 1 current transformer clamp C148 (configurable 250/500/1000 A; 1 kHz)
  • 5 cables with fuses for voltage measurement
  • Safety test probes (crocodile clips, magnetic test probes, test probes for use with push-wire terminals)
  • Trolley
  • Case can be locked (padlock not included)

  • Features
  • Applications
  • Ordering information
  • Downloads
  • Class A power analyser certified acc. to DIN EN 61000-4-30
  • Voltage quality monitoring acc. to DIN EN 50160
  • Accuracy class acc. to IEC 62053-22: 0.2 S
  • TFT colour display (640x480) 5.7“
  • Modbus TCP
  • 4 current inputs
  • 5 voltage inputs (3L/N/PE)
  • 1 GB internal memory
  • An integrated web server
  • Flicker measurement
  • Transient detection and recording (40 µs)
  • Sampling rate: 512 samples/cycle
  • Individually configurable recorder for waveforms, consumption, long-term recordings
  • Continuous monitoring of the voltage quality in accordance with DIN EN 50160
  • Collection of relevant data for energy management systems
  • High-resolution waveform recording allows analysis of power quality phenomena


Variants of LINETRAXX® PEM735-measuring case

TypeArt. No.
PEM735 measuring caseB98300014
